Frame

Crafty 6061 Alloy Stealth Evo, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.

Sizes

S: 380mm / M: 420mm / L: 450mm / XL: 490mm

REAR SHOCK

Fox Float-X LV Factory Kashima, 205x65mm. Settings: compression 2 positions lever, low-speed compression, low-speed rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

Shock Settings

Medium compression, medium rebound, air volume spacer 0.2

Fork

Fox 38 29 Float GRIP2 Factory Kashima, 160mm, e-bike tuned, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high and low-speed compression, high and low-speed rebound, air preload

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

Stem

Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

GRIPS

Onoff Desert, 1lock-on, 135mm

SEATPOST

Fox Transfer Factory Kashima internal, diameter 31.6mm, S size: 363.5x125mm, M size: 418.3x150mm, L size: 475.1x175mm, XL size size: 475.1x200mm

SADDLE

FIZIK Terra Aidon X5 145mm

FRONT BRAKE

Sram Code Bronze, oversized 4-piston caliper, Centerline 220mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

REAR BRAKE

Sram Code Bronze, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

BRAKE LEVER

Sram Code Bronze Stealth, SwingLink and lever pivot bushings, tool-free reach adjust

RIMS

Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

SPOKES

Mavic J-bend double butted, contactless lacing

FRONT HUB

Mavic, Boost 15x110mm, IS 6 bolts

REAR HUB

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub

FRONT TYRE

Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

REAR TYRE

Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

CRANKSET

Race Face Aeffect ebike, 165mm

RINGS

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

CHAIN

Sram NX Eagle, 12s, Powerlock

REAR DERAILLEUR

Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

SHIFT LEVERS

Sram Trigger GX Eagle, 12s, X-Actuation 1:1, single click

CASSETTE

Sram PG-1230, 11-50T, 12s

DERAILLEUR HANGER

Mondraker M068

WEIGHT

25.9 kg

DISPLAY

Bosch Kiox 500 / Bosch Mini Remote / Bosch System Controller

MOTOR

Bosch Performance Line CX Cruise (32km/h) GEN4 SMART SYSTEM

BATTERY

Bosch Powertube 750Wh
