Frame

6061 Alloy Stealth Evo, hydroformed tubing, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.

Sizes

S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm

REAR SHOCK

Rockshox Deluxe Select+, 185x55mm, Trunnion top mount, 30x8mm bottom bushings

Shock Settings

L compression, digressive rebound, 4 tokens

Fork

Rockshox Psylo Gold RC, 160mm, 3 Position, Debon Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Headset

Acros custom IS52/ZS56, 1-1/8", 1.5" head tube, Internal cable routing, sealing plugs without blocklock

Stem

Onoff S3 30mm 0º, 6061 forged alloy, 31.8mm barbore

Handlebar

Onoff S3 1.0 6061 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 1.5 rise.

GRIPS

Onoff Forest, CNC lock-on, 135mm

SEATPOST

Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 140-115mm (388-235mm), M size: 160-135mm (428-255mm), ML size: 180-155mm (468-275mm), L size: 210-185mm (528-305mm), XL size: 210-185mm (528-305mm)

SADDLE

Fizik Terra Aidon X5 145mm

FRONT BRAKE

Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

REAR BRAKE

Sram DB8 stealth, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads

BRAKE LEVER

Sram DB8, SwingLink and lever pivot bearings, tools-free reach and contact point adjust

RIMS

Mavic E-CrossRide 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

SPOKES

Mavic J-bend double butted, contactless lacing

FRONT HUB

Mavic, Boost 15x110mm, IS 6 bolts

REAR HUB

Mavic, Boost 12x148mm, ID360 Ratched system, IS 6 bolts, HG freehub

FRONT TYRE

Maxxis Minion DHF 29x2.5 WT, tubeless ready, 3C MAXX GRIP compound, EXO+ protection, 60TPI, folding bead

REAR TYRE

Maxxis Minion DHR II 29x2.5 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 60TPI, folding bead

CRANKSET

e*Thirteen Helix Core E*Spec Plus, All sizes: 160mm

RINGS

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

CHAIN

Sram GX Eagle T-Type, 12s, Powerlock

REAR DERAILLEUR

Sram S1000 Eagle AXS T-Type, 12s

SHIFT LEVERS

Sram Eagle AXS Pod MMX, 12s

CASSETTE

Sram XS-1270, 10-52T, T-Type, 12s

WEIGHT

20,9 kg

DISPLAY

Purion 400 / Bosch Mini Remote / Bosch System Controller

MOTOR

Bosch Performance Line SX (32Km/h) GEN4 SMART SYSTEM Diagonal, Wide

BATTERY

Bosch Compact Powertube 400Wh
