Frame

Thundra 6061 Xtralite Full Butted Alloy, Forward Geometry, integrated internal non-removable battery, tapered head tube, Boost 12x148mm rear axle, integrated dropout speed sensor.*Optional external battery

Sizes

S: 390mm / M: 430mm / L: 470mm / XL: 510mm

Fork

RockShox Recon Silver RL 29, 120mm, Motion control, Solo Air, tapered steerer tube, Boost 15x110mm axle, 42mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload

Headset

Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41 x 30.2 x 7 x 45º x 45º, bottom 51.9 x 40 x 8 x 45º x 45º

Stem

MDK Urban 40mm 5º, 6061 forged alloy, 31.8mm barbore

Handlebar

MDK Urban 1.0 double butted 6061 alloy, rise: 20mm, width: 680mm, 9º backsweep, 5º upsweep, 31.8mm barbore

GRIPS

Onoff Shaper

SEATPOST

Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 31.6mm, length 400mm

SADDLE

MDK urban

FRONT BRAKE

Sram Level T, 2 piece caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pad

REAR BRAKE

Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad

BRAKE LEVER

Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings

RIMS

MDK-HP1 29, 30mm internal width, tubeless ready, 32 spokes

SPOKES

CN round stainless steel

FRONT HUB

Formula DC711, Boost 15x110mm, sealed bearings, IS 6 bolts

REAR HUB

Formula EHL148 Boost 12x148mm, sealed bearings, IS 6 bolts

FRONT TYRE

Maxxis Grifter 29x2.5, single compound, 60TPI, wire bead, tanned wall.

REAR TYRE

Maxxis Grifter 29x2.5, single compound, 60TPI, wire bead, tanned wall.

CRANKSET

FSA Shimano EP8, 165mm

RINGS

Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

CHAIN

Sram SX Eagle, 12s, Powerlock

REAR DERAILLEUR

Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1

SHIFT LEVERS

Sram Trigger SX Eagle, 12s, X-Actuation 1:1, single click

CASSETTE

Sram PG-1210, 11-50T, 12s

DERAILLEUR HANGER

Mondraker M068

OTHERS

Front light: 50LUX output DC 6-12V, waterproof Alloy cage. Rear Light: Fender Mount, w/ Reflective, e-bike version, 6-12V. Fenders: Alloy black MDK custom fenders. Rack: Alloy MDK rear Rack, Max loading 25kg. Kickstand: Massload KSA18-40. *Optional external battery: Simplo 360Wh

WEIGHT

23,8 kg

DISPLAY

Shimano EN500

MOTOR

Shimano STEPS EP600

BATTERY

Simplo internal 720Wh
